High-Temperature Warp Beam Dyeing Machine

Ask Lasest Price
Brand Name :	Alees
Model Number :	AS-JRJ-HT
Certification :	CE
Price :	USD5000-250000
Delivery Time :	6-9 weeks
Supply Ability :	50 sets per month

Add to Cart

Product Details
Company Profile

High-Temperature Warp Beam Dyeing Machine

Introduction

Suitable fabric: Viscose,nylon,elastic fabric,silk,cotton,polyester,blended fabric.

Technical Parameters

-Rolling diameter: Φ1000mm/Φ1200mm
-Roller width: 2000~4000mm
-Efficient width: 1800~3800mm
-Speed: 0~130m/min
-Tension range: 0~60KG
-Temperature control range: 0-135℃
-Rolling roller diameter: Φ300mm
-Motor power of main roller 2 sets are 5.5KW

-Tank body mobile motor power 0.75KW
-Motor power of circulating pump 2.2KW

Model and Specifications

Model	AS-JRJ-HT-800			AS-JRJ-HT-1200			AS-JRJ-HT-1400
Roller width(mm)	2000	3200	3400	2000	3200	3400	2000	3200	3400
A(mm)	800	800	800	1200	1200	1200	1400	1400	1400
B(mm)	1800	3000	3200	1800	3000	3200	1800	3000	3200
C(mm)	1850	1850	1850	2300	2300	2300	2650	2650	2650
D(mm)	4450	4450	4450	4850	4850	4850	5010	5010	5010
E(mm)	6000	8400	8800	6500	9800	9300	6600	9000	9400
F(mm)	7000	9400	9800	7500	9900	10300	7600	10000	10400
G(mm)	2300	2300	2300	2500	2500	2500	2550	2550	2550
H(mm)	2500	2500	2500	2700	2700	2700	3200	3200	3200
